Blue Sea A Series Flat Circuit Breaker/ Switch 5A

Blue Sea A Series Flat Circuit Breaker/ Switch 5A

SKU: 8-27400 MPN: 7400-BSS
cancel Out of Stock
£23.51 exc VAT

Prices exclude VAT. Trade pricing available on request.

info Quick Overview

Description

A-SERIES FLAT ROCKER CIRCUIT

BREAKERS (AC/DC)

Standard circuit breaker used on the 360 Panel System (1200 Series)

Flat actuator resists accidental switching by being flush in the

ON position

White actuator indicates OFF position

Single pole is frequently used for AC or DC Branch circuit protection

International ON & OFF symbols support vertical or horizontal mounting

• Regulatory: CE marked

• TUV certified, CSA certified,

• UL 1077 recognized

• Voltage max operating: 32V DC / 250V AC

• Temp operating: Min: -40°C, Max: 85°C

• Switching cycles: 10,000 @ rated A & V

• Type: Magnetic hydraulic -Trip free

• Terminal Screw: #10-32 Stainless Steel

• Terminal screw torque: 14-15 in-lb Recommended(load terminal is 30° angled)

• Mounting screw: #6-32 Stainless Steel

• Mounting screw torque: 6-8 in-lb Recommended

Read Full Description arrow_downward
anchor

Out of stock

Get a Custom Quote

This item is currently out of stock. Send us your details and we will re-source availability, then get back to you with a custom quote as soon as possible.

Product: Blue Sea A Series Flat Circuit Breaker/ Switch 5A
SKU: 8-27400

Thank you. Once submitted, our team will review your request and contact you by email or phone as soon as possible.

lock Secure 256-bit Checkout
verified_user Official Marine Warranty
local_shipping Fast UK Delivery
support_agent Expert Marine Support
assignment_return 30-Day Returns

Description

A-SERIES FLAT ROCKER CIRCUIT

BREAKERS (AC/DC)

Standard circuit breaker used on the 360 Panel System (1200 Series)

Flat actuator resists accidental switching by being flush in the

ON position

White actuator indicates OFF position

Single pole is frequently used for AC or DC Branch circuit protection

International ON & OFF symbols support vertical or horizontal mounting

• Regulatory: CE marked

• TUV certified, CSA certified,

• UL 1077 recognized

• Voltage max operating: 32V DC / 250V AC

• Temp operating: Min: -40°C, Max: 85°C

• Switching cycles: 10,000 @ rated A & V

• Type: Magnetic hydraulic -Trip free

• Terminal Screw: #10-32 Stainless Steel

• Terminal screw torque: 14-15 in-lb Recommended(load terminal is 30° angled)

• Mounting screw: #6-32 Stainless Steel

• Mounting screw torque: 6-8 in-lb Recommended

Brand

Blue Sea Systems
Amps Description

5A
Mounting Description

Panel Mount
