Description
Provides medium duty circuit protection for 150 Amp loads when switching and circuit protection are both required.
– Trip-free – cannot be held closed after trip
– Visible reset lever shows open condition
– Drop-in replacement for 185-Series Circuit Breakers
Regulatory:
– CE marked
– Meets SAE J1171 external ignition protection requirements, †AIC ratings achieved using SAE J1625
– IP67 – protected against immersion up to 1 meter for 30 minutes
Specifications:
Interrupting Capacity: 3000A at 48V DC
Vmxo: 48V DC
Operating Temperature: -40 C min to +85 C max
Type: Thermally Responsive Bi-Metal Blade
Class: Type III Switchable/Manual Reset – Trip Free
Terminal Stud: M6
Terminal Stud torque: 50 in-lb
Mounting: 1/4″ Screw
